I. Oscillation
The oscillation function is used to move the monitor back and forth inside a boxed area or straight
horizontal or vertical line specified by the user.
Move the monitor to one corner of the intended boxed area (For a straight horizontal or vertical
line, move monitor to the first line endpoint).
Press the OSCILLATE button
Move the monitor to the opposite corner of the intended boxed area (For a straight horizontal or
vertical line, move monitor to the opposite endpoint of the line.)
Press the OSCILALTE button a second time
The monitor should begin moving up and down, and left and right within the boxed area. (If
setting a horizontal or vertical line, monitor should begin oscillating horizontally or vertically
only.)
If there is no monitor movement for 30 seconds while setting up the oscillation limits, the monitor
will automatically exit oscillate setup
Pressing UP, DOWN, LEFT, RIGHT, or OSCILLATE will stop oscillation of a boxed area (Pressing
LEFT, RIGHT, or OSCILLATE will stop horizontal oscillation while pressing UP, DOWN, or
OSCILLATE will stop vertical oscillation.
o
All other functions can be operated without stopping oscillation.
J. Handheld Controller Sleep / Hibernation Mode
Sleep Mode – The Handheld Controller will go into sleep mode after one minute of inactivity. The
blue power LED will blink every three seconds while in sleep mode. Any button press will wake the
unit up.
Hibernation Mode – After 5 minutes of inactivity the handheld will go into hibernate mode. All
LEDs will be off when the handheld is in hibernate mode. The AUX button is the only button that
must be pressed to turn the handheld on at that point.
o
The handheld can be placed in hibernate mode by pressing and holding the AUX button
until the power LED turns off.
K. Valve Operation
OPEN – opens the valve. If the button is released, the valve will remain in the current position
until another valve operation is performed.
o
In order to initiate auto-travel open, press and hold the OPEN button, then press and release
the CLOSE button, then release the OPEN button. The valve will then auto-travel to fully
open.
CLOSE – closes the valve. If the button is released, the valve will remain in the current position
until another valve operation is performed.
o
In order to initiate auto-travel close, press and hold the CLOSE button, then press and
release the OPEN button, then release the CLOSE button. The valve will then auto-travel to
fully closed.
