Det-Tronics X5200 UVIR Flame Detector with HART User Manual

Page 18

95-8636

2.1

conFigurAtion menu

1) consecutive uv oi Fails

Allowable number of consecutive UV Oi failures to produce a fault. Factory set to 3

(minutes). This is the time between fault occurrence and annunciation.

2) consecutive ir oi Fails

Allowable number of consecutive IR Oi failures to produce a fault. Factory set to 3

(minutes). This is the time between fault occurrence and annunciation.

3) time delay

Time Delay before alarm is indicated (0 to 15 seconds). Factory default is 0 seconds.

important: In addition to lengthening the time period between the outbreak of a fire and
the fire alarm, a time delay can also affect sensitivity. Consult the factory for guidance
before setting a time delay over 5 seconds.

note: FM Approval covers the detector's performance with 0 (zero) time delay only.

cALiBrAtion menu

1) Loop test

This test allows the operator to manually set the analog signal output to a fixed user

defined value. (Range: 0-20 mA).

2) d/A trim

This function allows adjustment of the 4-20 mA span factor.

3) calibrate oi

This procedure calibrates the Oi test signal for the UV and IR sensors.

1. Bypass/disable all Alarm outputs connected to the detector.

2. Thoroughly clean the sensor and Oi reflector for the UV and IR sensors.

Check the Oi source openings for contaminants and clean as needed.

3. Cover the detector with the provided cover.

4. Initiate Oi Calibration. The detector performs the calibration automatically and

notifies the operator upon completion. The procedure takes approximately two

minutes.

5. Upon completion of Oi calibration, remove the cover and return all alarm outputs

to service.

Configuration Menu

1) Consecutive UV Oi Fails
2) Consecutive IR Oi Fails
3) Time Delay

Device Setup Menu

1) Configuration Menu
2) Calibration Menu
3) Write Protect
4) HART Setup
5) Set Real Time Clock

X5200 Root Menu

1) Fire (Yes/No)
2) Fault (Yes/No)
3) Device Info Menu
4) Command Menu
5) Device Setup Menu

Calibration Menu

1) Loop Test
2) D/A Trim
3) Calibrate Oi

Device Setup Menu

1) Configuration Menu
2) Calibration Menu
3) Write Protect
4) HART Setup
5) Set Real Time Clock

X5200 Root Menu

1) Fire (Yes/No)
2) Fault (Yes/No)
3) Device Info Menu
4) Command Menu
5) Device Setup Menu
