95-8636 2.1 11
hArdwAre menu
1) temperature Actual integral temperature of detector (in degrees Celsius).
2) temp range Fault Detector integral temperature out of range —
Operating range: –40°C to +75°C (–40°F to +167°F).
3) voltage Actual detector supply voltage (must be 18 to 30 Vdc).
4) volt Fault Supply voltage is out of range. Operating voltage must be 18 to 30 Vdc.
5) manual oi at start Manual Oi at Start. On power-up a manual Oi was started. Check the external input wiring.
oi menu
1) consecutive uv oi Fails Allowable number of consecutive UV Oi failures to produce a fault. Factory set to 3
(minutes). This is the time between fault occurrence and annunciation.
2) consecutive ir oi Fails Allowable number of consecutive IR Oi failures to produce a fault. Factory set to 3
(minutes). This is the time between fault occurrence and annunciation.
3) oi calibrate Active Oi calibration is in progress.
4) uv oi cal Fault UV Oi calibration has detected a fault condition.
5) ir oi cal Fault IR Oi calibration has detected a fault condition.
6) manual oi Active A manual Oi test is in progress.
7) manual uv oi Fault Manual UV Oi fault. Check UV viewing window and Oi reflector plate cleanliness.
8) manual ir oi Fault Manual IR Oi fault. Check IR viewing window and Oi reflector plate cleanliness.
Hardware Menu
1) Temperature
2) Temp Range Fault
3) Voltage
4) Voltage Fault
5) Manual Oi at Start
Device Info Menu
1) General Info Menu
2) HART Info Menu
3) Status Info Menu
4) Detector Settings
5) History Menu
X5200 Root Menu
1) Fire (Yes/No)
2) Fault (Yes/No)
3) Device Info Menu
4) Command Menu
5) Device Setup Menu
Status Info Menu
1) Warmup (Y/N)
2) Fire (Y/N)
3) UV Alarm (Y/N)
4) IR Alarm (Y/N)
5) TDSA Alarm (Y/N)
6) Quick Alarm (Y/N)
7) UV Pre Alarm (Y/N)
8) IR Pre Alarm (Y/N)
9) Auto UV Oi Fault (Y/N)
10) Auto IR Oi Fault (Y/N)
11) Manual Oi at Start
12) Snsr Hdwr Fault (Y/N)
13) HIB Hdwr Fault (Y/N)
14) Int Comm Fault (Y/N)
15) Incompatible Fault (Y/N)
16) Voltage Fault (Y/N)
17) Hardware Menu
18) Oi Menu
Device Info Menu
1) General Info Menu
2) HART Info Menu
3) Status Info Menu
4) Detector Settings
5) History Menu
X5200 Root Menu
1) Fire (Yes/No)
2) Fault (Yes/No)
3) Device Info Menu
4) Command Menu
5) Device Setup Menu
Oi Menu
1) Consecutive UV Oi Fails
2) Consecutive IR Oi Fails
3) Oi Calibrate Active
4) UV Oi Cal Fault
5) IR Oi Cal Fault
6) Manual Oi Active
7) Manual UV Oi Fault
8) Manual IR Oi Fault
Status Info Menu
1) Warmup (Y/N)
2) Fire (Y/N)
3) UV Alarm (Y/N)
4) IR Alarm (Y/N)
5) TDSA Alarm (Y/N)
6) Quick Alarm (Y/N)
7) UV Pre Alarm (Y/N)
8) IR Pre Alarm (Y/N)
9) Auto UV Oi Fault (Y/N)
10) Auto IR Oi Fault (Y/N)
11) Manual Oi at Start
12) Snsr Hdwr Fault (Y/N)
13) HIB Hdwr Fault (Y/N)
14) Int Comm Fault (Y/N)
15) Incompatible Fault (Y/N)
16) Voltage Fault (Y/N)
17) Hardware Menu
18) Oi Menu
