95-8555 5.1 2
OUTpUTS
Relays
The detector is furnished with fire and fault relays. The
relays are rated 5 amperes at 30 Vdc.
The Fire Alarm relay has redundant terminals and
normally open / normally closed contacts, normally
de-energized operation, and latching or non-latching
operation.
The Fault relay has redundant terminals and normally
open contacts, normally energized operation, and
latching or non-latching operation.
Latching relays can be reset by removing input power
(0.1 second minimum).
An alarm condition will normally over-ride a fault
condition, unless the nature of the fault condition impairs
the ability of the detector to generate or maintain an
alarm output, i.e. loss of operating power.
LED
A tri-color LED on the detector faceplate indicates
normal condition and notifies personnel of fire alarm
or fault conditions. Table 1 indicates the condition of the
LED for each status.
oi
(OpTICaL INTEgRITy)
automatic oi
The X9800 includes the Automatic oi feature — a
calibrated performance test that is automatically
performed once per minute to verify complete detector
operation capabilities. No testing with an external test
lamp is required. The detector automatically performs
the same test that a maintenance person with a test
lamp would perform — once every minute. However, a
successful Automatic oi test does not produce an alarm
condition.
The X9800 signals a fault condition when less than half
of the detection range remains. This is indicated by the
fault relay and is evident by the yellow color of the LED
on the face of the detector. See the “Troubleshooting”
section for further information.
Magnetic oi / Manual oi
CaUtIon
These tests require disabling of all extinguishing
devices to avoid release resulting from a
successful test.
The detector incorporates both Magnetic oi (Mag oi)
and Manual oi (Man oi) test capabilities. These tests
provide pulses (80 to 100 CPS) to the controller (R7404
or R7494) when the detector is not in fault. If the test
is successful, the controller indicates a fire and the
appropriate zone output is active.
NOTE
If the detector is in a fault condition, a successful
Mag
oi or Man oi test cannot be performed.
The Mag oi test is performed by placing a magnet at the
location marked “MAG OI” on the outside of the detector
(see Figure 2). This action causes the detector to
immediately send pulses to the controller. Controller
response is as follows:
• The Zone LED blinks.
• The digital display indicates which Zone is in alarm.
• The status indicator shows “6” (fire).
Table 1—Detector Status Indicator
Detector Status LED Indicator
Power On/Normal Auto oi
(no fault or fire alarm)
Green
Power On/Normal Man oi
Green, flashing on for
0.5 sec. every 5 sec.
Fault Yellow
Pre-Alarm/Background IR
Red, flashing on for
0.5 sec. and off for 0.5 sec.
Fire (Alarm) Steady Red
On Power-Up, The LED Flashes in Sequence as Follows,
Indicating Sensitivity and Signal Processing Status
Low IR Sensitivity
Medium IR Sensitivity
High IR Sensitivity
Very High IR Sensitivity
One Green Flash
Two Green Flashes
Three Green Flashes
Four Green Flashes
Quick Fire / TDSA IR Signal
TDSA only IR Signal
Quick Fire only
One Yellow Flash
Two Yellow Flashes
Three Yellow Flashes
