24
Sequence of Operation (system using Beacon Light)
This section describes operation of the oven with the optional beacon light feature.
1.
After the system is powered up (see above procedure), the Protocol Plus
controller is initialized.
2.
At this point the oven is idle, empty, door closed, and waiting for the next lot to be
processed. The Protocol Plus is not running a profile. The amber beacon light is
on steady for steps 2 through 5, until profile is started. Refer to the Protocol Plus
instructions in this manual.
3. Open the oven door. The red pilot light on the sterile side (STERILE DOOR
OPEN) is on.
4.
Place the product on the shelf in the oven. Close the oven door. Red pilot light
on sterile side is off.
5. Run the desired profile from the Protocol Plus controller.
Press the Select key until Profile is displayed (you can press the Run key at
any time to activate Profile Mode).
Press the key to display the desired profile to run.
To start Profile Mode, press the Run key.
NOTE: The display will change from Stop to Run and the segment time
remaining, along with the current segment number, will be displayed.
6.
The oven profile cycle is in process and both doors are LOCKED. The yellow
pilot light on the sterile side (CYCLE ON) is on. The green beacon light is on
steady, the amber beacon light is off.
7.
When the process is complete, the green illuminated push button on the sterile
side (CYCLE COMPLETE) is on, and the amber beacon is on.
8.
Press the STERILE DOOR UNLOCK pushbutton on the sterile side, and open
the oven door to remove the product workload.
9. The operator closes oven door and presses the green illuminated push button
(CYCLE COMPLETE) to complete the process cycle.
10.
The yellow pilot light on the non-sterile side (DOOR RELEASE) is on, and the
amber beacon is on. The oven is ready for the next lot.
