4
Physical Specifications
ENGLISH METRIC
CHAMBER VOLUME 14 cubic feet 396 liters
INTERNAL
DIMENSIONS *
25.5” W x 26”D x 37” H
65 cm W x 66 cm D x 94 cm H
EXTERNAL
DIMENSIONS
48” W x 40 “ D x 71 “ H
122 cm W x 102 cm D X 180 cm
H
SHELF SUPPORTS
Quantity 11 on 3” centers Quantity 11 on 7.6 cm centers
SHELF LOAD
CAPACITY 50 pounds 22.6 kg
CHAMBER LOAD
CAPACITY 400 pounds 181 kg
NET WEIGHT
955 pounds 433 kg
SHIPPING WEIGHT
1050 pounds 476 kg
RECIRCULATION
FAN 950 cfm 27 cmm
* Clear width reduced to 24” (61cm) by shelf supports.
Functional Specifications
MODEL
ATMO-
SPHERE
OPERATING
RANGE
HEATING TIME TO TEMP
(minutes, w/no load)
COOLING TIME TO TEMP
(minutes, w/no load)
TEMPERATURE
UNIFORMITY AT
CONTROL
STABILITY
50-
100°C
50-
175°C
50-
260°C
50-
350°C
100-
65°C
175-
65°C
260-
65°C
350-
65°C
100°C 175°C 260°C 350°C
LCC/LCD
2-14 PT3
AIR 60°C - 260°C 3 9 15 35 41 82 95 117 ±1°C ±2°C ±3°C ±3.5°C ±0.5°C
1. Uniformity figures are based on a nine-point test conducted in an empty oven
with thermocouples positioned at 3” from walls, and after the oven temperature
has reached stabilization (typically 30
– 60 minutes). Uniformity can vary slightly
depending on unit and operating conditions.
2. Operating temperatures and cooling times are based on a 20°C ambient
temperature measured at the fresh air inlet.
3. Exhaust fan specification is 85 cfm.
