1
INTRODUCTION
The LCC/LCD2-14PT-3 SERIES pass-through oven is equipped with sterile and non-
sterile doors, for clean room operation. Safety interlock switches on each door prevents
both doors to open at the same time (these may be manually overridden if required).
The operator loads the product from the non-sterile side, and selects the program to
run. At the end of the process, the product is unloaded from the sterile side.
The LCC/LCD2-14PT-3 SERIES pass-through oven offers HEPA filtration for processes
where minimization of contamination is essential. The removable HEPA (High Efficiency
Particulate Air) filter is designed to provide a constant flow of 99.97% clean air to the
product being heated. The HEPA filter with silicone seal provides 99.99% filtration prior
to filter burnoff. A magnehelic differential pressure gauge monitors pressure drop
across the HEPA filter.
The LCC2-14PT-3 Series ovens are rated up to 260 C, and the LCD2-14PT-3 Series
has a maximum temperature of 350 C.
The voltages available are 208V, 240V, 415V, and 480V,
3 Phase; with a 16kW heater.
The oven’s main operator interface components are on the hinged control panel located
on the non-sterile side. The power components; fuse blocks and motor starters are
located on the equipment panel, behind the hinged control panel for easy access. The
transformer and the heater SS
R’s are located in the lower compartment with the
recirculation and exhaust/cooling motors. An EMO (emergency off) switch, and
indicator lights showing what step the process is in, is located on the sterile side control
panel. Electrical components are either touch-proof or are shielded with Lexan to
prevent accidental exposure during maintenance and troubleshooting.
The optional Despatch Protocol Manager software is used to enable customer PC
control of an oven. Despatch Protocol Plus controllers may be networked together with
a Modbus communication option when multiple ovens are operated.
Atmosphere Max Temp C Model
Air 260 LCC2-14PT-3
Air 350 LCD2-14PT-3
