23
Operating Procedure
Starting the Oven
1.
Turn the yellow/red DISCONNECT SWITCH to ON.
2.
Press the POWER pushbutton ON switch.
The green CYCLE COMPLETE illuminated push button will be lit (sterile
side). If required, the sterile door may be opened (non-sterile door will be
locked); otherwise, depress the CYCLE COMPLETE illuminated push
button. This will reset the oven, indicating oven is ready for new process.
To open the oven door, press the STERILE DOOR UNLOCK pushbutton
and at the same time, press on the door. The oven door will unlatch and
open.
(optional beacon light-equipped units) The amber (center) beacon light will
illuminate, indicating that the oven is waiting for new process to start.
3.
The non-sterile DOOR RELEASE pushbutton will illuminate. This means the
door can be opened (sterile door will be locked).
(optional beacon light-equipped units) The amber (center) beacon light will
illuminate, indicating that the oven is ready to receive work to be
processed.
4.
To open the oven door, press the DOOR RELEASE pushbutton and at the same
time, press on the door. The LED on the door lock switch will illuminate,
indicating the solenoid has been energized. The oven door will unlatch and
open.
5.
NOTE: During the process cycle, both doors will remain locked. The door lock
switches has manual override for authorized maintenance personnel to release
door in case of power failure.
6.
If the oven needs to be shut down in an emergency:
From the non-sterile side, turn the disconnect switch to OFF. Reset by
turning the disconnect switch back to ON. Go to step two (2) for restarting
oven.
From the sterile side, push the EMO switch in. Reset by pulling switch
out. Go to step two (2) for restarting oven.
