Despatch LBB2-xxA/B-2 - Manual (Page 64)

A PPENDICES LBB Series Oven Owner’s Manual
64 Version 18
8.3. Part Lists
Find many parts for Despatch ovens online at
www.despatch.com/parts.aspx.
8.4. Mechanical Drawing
•
LBB1-23: Figure 28
•
LBB1-69: Figure 29
•
LBB2-12: Figure 30
•
LBB2-18: Figure 31
•
LBB2-27: Figure 32
8.5. Electrical Schematics
The following pages provide electrical schematics for these LBB Series ovens:
•
LBB Standard (120 V): Figure 33
•
LBB Standard (240 V): Figure 34 Figure 34
•
LBB Opt P-3 (120 V): Figure 35 Figure 35
•
LBB Opt P-3 (240 V): Figure 36 Figure 36
Note that each schematic also includes wiring for the Timer (8.2.2) and High Limit Alarm (8.2.6)
options.
