LBB Series Oven Owner’s Manual M AINTENANCE
Version 18 45
3. Slide the panel forward (Figure
14). Support the panel while
working by wedging a flat
surface between the oven door
and oven ceiling.
4. Remove wires from the old control instrument (using P1 Phillips screwdriver), carefully
noting which wires connect to which terminals (Figure 15).
Thermocouple wires
Control Instrument
High Limit
Instrument
Figure 15. Remove old Control and High Limit Instruments and Wiring (Rear View).
Figure 14. Providing easy access to the Control instrument.
