LBB Series Oven Owner’s Manual O PERATION
Version 18 31
c. Press to enter the setpoint.
d. Press again to display the process temperature.
5. Turn HEATER ON.
a. When the process value on the Control instrument reaches setpoint, OUT cycles ON and
OFF to maintain the temperature setpoint.
b. OUT lights when the control calls for heat.
6. Turn HEATER OFF after the heating cycle is complete.
7. Do not turn the fan OFF until the oven chamber temperature is below 100
◦
C (212
◦
F).
Warning!
Damper may be hot at elevate temperatures.
Figure 11. LBB Series Oven Control Panel.
Figure 12. Adjust Damper to Set Exhaust Vent by rotating the outer component.
