M AINTENANCE LBB Series Oven Owner’s Manual
46 Version 18
Control Instrument
Mounting Bracket
Figure 16. Prepare to remove control instrument by removing the mounting bracket.
5. Move the Control instrument mounting bracket back and off (Figure 16).
6. Remove old Control instrument from the panel.
7. Install new Control instrument into the control panel.
8. Secure instrument mounting bracket.
9. Reattach wires to the new Control instrument. Double-check that the wires are connected
correctly. See Figure 17 for correct Control instrument connections.
10. Reinstall control panel.
Figure 17. Connections to Control Instrument.
