8.2. LAC-7 Series Oven Options
8.2.1. Optional MRC5000 Recorder Setup

Refer to instructions provided by the recorder manufacturer for
more specific installation notes.
Temperature is retransmitted to the MRC5000 recorder from the controller. To set up the
recorder:
1. Ensure hardware jumper JU1 is in place for the 5 VDC setting (Refer to MRC5000 Manual
included).
2. Move MODE to PROG/TEST/CAL to display Prog .
3. Press ▼ twice to display Inps
. Move to each Parameter Code using ▼or ▲. Adjust each
Parameter Code using the settings in Table 5.
4. After adjusting all settings, move MODE to RUN . Display on both the recorder and controller
should read the same.
Table 5. MRC 5000 Settings.
Parameter Code
Degrees C Degrees F
Inps 18 18
Icor 0 0
diSP On On
dPOS 0 0
EUU
6
400 752
EUL 6 0 32
ChUP 400 800
7
ChLO 0 0
DFF 1 1
6 These values must match the settings RetOutLo and RetOutHi on the Protocol 3 control page. For
example, if RetOutLo is 32, EUL must read 32.
7 Change 0-400 chart paper to 0-800 chart paper. Depending on the equipment used, 0-600 paper may be
used if the maximum temperature is 500°F.
