CONDUX WINCH LINE BLOWER

4

Winch Line Blower Seal-Off Selection

1.

Determine type(s) and diameter(s) of conduit in which the winch line will be inserted.

2.

Select the correct threaded adpater to cover the range of conduit types and sizes

being used.

3.

Select the proper size rope venture. Comes standard with ½” – 9/16” venture.

4.

Select the proper missile size for the conduit sizes that are going to be used.

Threaded Adapter

Rope Venturi

Winchline Blower Body
