CONDUX WINCH LINE BLOWER 8
7. Close winchline blower body and secure by tighten the speedball handle securely. do
not over tighten. See Figure 7
!WARNING: The Threaded Adapters should be screwed tight into the duct to
ensure that the Winchline blower does not blow out of the conduit and severely
injure persons or damage property.
Figure 8: Align The Winch Line
8. Ensure that winchline is entering in a straight line. Check the winch line alignment to
ensure that the winch line is not hung up or restricted and that it will feed through the
winchline blower smoothly. See Figure 8
!CAUTION: Always guide the winch line into the winchline blower parallel with
the center line of the conduit. Use additional sheaves or cable guides if
necessary.
Figure 7 Close and Secure Winchline Blower Body
