Condux Winch Line Blower System User Manual
Page 26
CONDUX WINCH LINE BLOWER
24
Winchline Blower Body Assembly
ITEM
PART
NUMBER
DESCRIPTION
QTY
1
08780126
3.5mm CS QUAD-‐RING KIT
1
2
02288000
MALE LOCKING COUPLER -‐ 1/2NPT-‐M
1
3
02288596
CAPSCREW,C-‐SINK M04-‐0.7 x 16MM 18-‐8SS
2
4
02288665
NUT,NYLOC M06-‐1.00 CZ
1
5
02288694
NUT,NYLOC M08-‐1.25 CZ
1
6
02288787
HEX DRIVER -‐ 2.5MM
1
7
02289293
SWING BOLT M10-‐1.50 x 125MM
1
8
02289294
SHOULDER SCREW M10 x 40MM (M08-‐1.25 THREADS)
1
9
02289295
SHOULDER SCREW M08 x 70MM (M06-‐1.00 THREADS)
1
10
02289297
CAPSCREW,C-‐SINK M06-‐1.0 x 12MM 18-‐8SS
4
11
02289382
NUT,NYLOC THIN M10-‐1.50 CZ
1
12
02290020
3/4O-‐RING MALE HEX PLUG FITTING
1
13
02290021
3/4O-‐RING MALE x 1/2NPT-‐F FITTING
1
14
08201081
BODY INSERT -‐ WLB
2
15
08201086
WINCHLINE VENTURI SET (1/2 -‐ 9/16) INCLUDED
1
15
08201089
WINCHLINE VENTURI SET (1/4 -‐ 3/8) AVAILABLE
15
08201090
WINCHLINE VENTURI SET (7/8) AVAILABLE
16
08764001
BODY COUPLING
2
17
08764006
SPEED BALL HANDLE (M10-‐1.50 THREADS)
1
