- 85 - Appendix
(Note) Enter the Digital Output(Optical) screen to configure further settings if you use the S/PDIF Out
connector(s) on the back panel for digital audio output or enter the Digital Output screen if you
use the internal S/PDIF Out connector (SPDIF_O) for digital audio output.
2. Configuring S/PDIF Out:
On the Digital Output(Optical) screen
(Note) , click the Default Format tab and then select the sample rate and
bit depth. Click OK to complete.
5-2-2 Configuring S/PDIF Out
The S/PDIF Out jack can transmit audio signals to an external decoder for decoding to get the best audio
quality.
1. Connecting a S/PDIF Out Cable:
Connect a S/PDIF optical cable to the corresponding S/PDIF out connector as shown below and an external
decoder for transmitting the S/PDIF digital audio signals.
Connects to a S/PDIF optical cable
