Hardware Installation - 10 -
1-2 Product Specifications
APU FM1 Socket: Š
- AMD A series processors
(Go to GIGABYTE's website for the latest APU support list.)
Chipset AMD A75 Š
Memory 4 x 1.5V DDR3 DIMM sockets supporting up to 32 GB of system memory Š
* Due to Windows 32-bit operating system limitation, when more than 4 GB of physical
memory is installed, the actual memory size displayed will be less than 4 GB.
Dual channel memory architecture Š
Support for DDR3 1866/1600/1333/1066 MHz memory modules Š
* The 1866 MHz memory speed is supported only when one or two DDR3 1866 MHz
DIMMs are installed. It is not supported when four DIMMs are installed. (Dual channel
memory mode must be enabled when installing two DIMMs.)
(Go to GIGABYTE's website for the latest supported memory speeds and memory
modules.)
Onboard
Graphics APU: Š
- 1 x D-Sub port
- 1 x DVI-D port, supporting a maximum resolution of 2560x1600
* The DVI-D port does not support D-Sub connection by adapter.
* The resolution of 2560x1600 is supported only when Dual Link DVI mode is enabled.
- 1 x HDMI port, supporting a maximum resolution of 1920x1200
- 1 x DisplayPort, supporting a maximum resolution of 2560x1600
(All integrated graphics ports do not support Hot plug. If you want to change to
another graphics port when the computer is on, be sure to turn off the computer
first.)
Audio Realtek ALC889 codec Š
High Definition Audio Š
2/4/5.1/7.1-channel Š
Support for Dolby Š ®
Home Theater
Support for S/PDIF Out Š
LAN 1 x Realtek RTL8111E chip (10/100/1000 Mbit) Š
Expansion Slots 1 x PCI Express x16 slot, running at x16 (PCIEX16) Š
* For optimum performance, if only one PCI Express graphics card is to be installed,
be sure to install it in the PCIEX16 slot.
1 x PCI Express x16 slot, running at x4 (PCIEX4) Š
1 x PCI Express x1 slot Š
(All PCI Express slots conform to the PCI Express 2.0 standard.)
1 x PCI slot
Š
Multi-Graphics
Technology
Support for AMD Dual Graphics technology Š
