- 11 - Hardware Installation
Storage Interface Chipset: Š
- 5 x SATA 6Gb/s connectors supporting up to 5 SATA 6Gb/s devices
- 1 x eSATA 6Gb/s port on the back panel supporting up to 1 SATA 6Gb/s
device
* Actual transfer rate is dependent on the device being connected.
- Support for RAID 0, RAID 1, RAID 10, and JBOD
USB Chipset: Š
- Up to 8 USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available
through the internal USB headers)
- Up to 4 USB 3.0/2.0 ports (2 ports on the back panel, 2 ports available
through the internal USB header)
IEEE 1394 VIA VT6308 Š chip:
- Up to 2 IEEE 1394a ports (1 on the back panel, 1 port available through the
internal IEEE 1394a header)
Internal
Connectors
1 x 24-pin ATX main power connector Š
1 x 4-pin ATX 12V power connector Š
5 x SATA 6Gb/s connectors Š
1 x APU fan header Š
1 x system fan header Š
1 x front panel header Š
1 x front panel audio header Š
1 x S/PDIF Out header Š
2 x USB 2.0/1.1 headers Š
1 x USB 3.0/2.0 header Š
1 x IEEE 1394a header Š
1 x serial port header Š
1 x parallel port header Š
1 x Trusted Platform Module (TPM) header Š
1 x clearing CMOS jumper Š
Back Panel
Connectors
1 x PS/2 keyboard/mouse port Š
1 x D-Sub port Š
1 x DVI-D port Š
1 x HDMI port Š
1 x DisplayPort Š
1 x optical S/PDIF Out connector Š
1 x eSATA 6Gb/s port Š
4 x USB 2.0/1.1 ports Š
2 x USB 3.0/2.0 ports Š
1 x RJ-45 port Š
6 x audio jacks (Center/Subwoofer Speaker Out/Rear Speaker Out/Side Speaker Š
Out/Line In/Line Out/Microphone)
I/O Controller iTE IT8720 chip Š
