59
Pulper/Water Extractor - Remote Control Cabinet
1
100095
SCREW, ROUND HD., 10-32 X 3/8" SST
14
2
100302
PILOT LIGHT, 120VAC, RED
1
3
100735
BOLT, HEX HD., 1/4-20 X 5/8" SST
4
4
102292
NAMEPLATE, ON-OFF
1
5
103310
GROUND, LUG
1
6
104873
LABEL, GROUND
1
7
106026
WASHER, FLAT 1/4 SST
4
8
106482
WASHER, LOCK 1/4 SST
4
9
106975
LABEL, 1CR
1
10
106976
LABEL 2CR
1
11
106977
LABEL, 3CR
1
12
106978
LABEL, 4CR
1
13
106980
LABEL, 1M
1
14
106981
LABEL, 2M
1
15
107096
LABEL, 3M
1
16
107098
LABEL, XFMR
1
17
107099
LABEL, 1MOL
1
18
107100
LABEL, 2MOL
1
19
107101
LABEL, 3MOL
1
20
107351
SWITCH, TOGGLE DPDT, ON/NONE/OFF
1
21
--- * ---
CONTACTOR, 3 POLE 120VAC COIL (Water Extractor & Recir. Pmp.) A/R
22
108311
CIRCUIT BREAKER, 3 AMP
1
23
108370
LOCK WASHER, ELECTRICAL
2
24
108498
LABEL, MAX FUSE AMP
1
25
108615
LABEL, MACH ELECTRICAL CONNECTION
1
26
--- * ---
STEP-DOWN TRANSFORMER, 250VA
1
27
--- * ---
CONTACTOR, MOTOR 3 POLE 120VAC COIL (Pulper Drive)
1
28
110346
LABEL, 5CR
1
29
110348
LABEL, 24V XFRM
1
30
110541
SHAFT, CIRCUIT BREAKER
1
31
--- * ---
CIRCUIT BREAKER
1
32
110612
NAMEPLATE, CIRCUIT BREAKER
1
33
110613
NAMEPLATE, FLUSHING VALVE
1
34
110628
NAMEPLATE, POWER ON
1
35
111036
SOCKET, RELAY, 2 POLE, 10A
5
36
111067
RELAY, 2 POLE, 10A, 24VAC COIL
1
37
111068
RELAY, 2 POLE, 10A, 120VAC COIL
4
38
111153
FUSE HOLDER ASSEMBLY
2
39
111162
NAMEPLATE, DELAY STOP
1
40
111277
TRANSFORMER, 120VAC:24VAC
1
41
111508
CIRCUIT BD. DEODORIZER SPEED CONTROL
1
42
111523
NAMPLATE, DEODORIZER ON/OFF
1
43
111615
PUSHBUTTON ASSY. RED
1
44
111617
CONTACT BLOCK, NO. START/STOP
1
(CONTINUED ON NEXT PAGE
Item Part
Description
Qty.
No. No.
ATTENTION
*
Refer to the Remote Control Cabinet Component Selection Chart at the end of the manual.
