Programming
9 MC18-GB – v1.04
Press Scroll

until the display shows. TEXT <ENABLE/DISABLE SCROLLING TEXT>
Use the Up
 Down 
to select
ON or OFF
4.6 Customer Calibration
The 3216 series of controllers are calibrated for life at manufacture, there may however be
sensor or other system errors, which affect the accuracy of the measured temperature.
Customer calibration can be used to compensate for these errors.
Dual Offset
Dual point calibration uses two offset values at two corresponding temperatures; this
changes the calibration linearly as the temperature increases or decreases.
Press scroll
 until the display shows CAL.P (Enter Calibration Code) Use Up 
Down

to enter the password code. (Calibration Pass Code = 95). When the correct password
has been entered the display will show
PNT.LO. If the wrong pass code is entered the display
will revert to zero pass code, until the correct pass code is entered.
When the correct pass code is entered and
PNT.LO (Adjust Low Point) is displayed. Use
Up

Down

to enter the Low Temperature Point, which you want to apply an Offset.
Press scroll

until the display shows OFS.LO (Adjust Low OFFset). Use Up

Down

to
enter the amount Offset you want to apply to the Low Temperature Point.
Press scroll

until the display shows
PNT.HI (Adjust High Point). Use Up 
Down

to enter the High Temperature Point, which you want to apply an Offset.
Press scroll

until the display shows
OFS.HI (Adjust High OFFset). Use the Up 
Down

to enter the amount Offset you want to apply the High Temperature Point.
Once the calibration details have been entered, press scroll

until the display shows the
next required parameter or return to the home list. The calibration data will now be protected
by the pass code. To edit the data the above procedure must be followed.
