Controller Fault

18

MC18-GB

– v1.04

8 Controller Fault

8.1

Fault Code Diagnostic Table

Error Code Explanation

Actions

S.br

Temperature sensor failure

Replace the Furnace or Oven
Temperature Sensor


9 Glossary of Terms

Process Value (PV)

The actual temperature of the furnace or oven.

°C

Setpoint (SP)

The target temperature the furnace or oven is trying to
reach.

°C

SP Ramp Rate

The speed at which the furnace or oven is allowed to
heat up or cool down.

°C/Min

Control Setpoint

The temperature that can be directly set into the
controller using the Up and Down keys

-

Element

The heating device used in the furnace or oven.

-

Thermocouple

The temperature-measuring device used in the furnace
or oven.

-

PID

Proportional Integral Derivative: the control system used
by the controller.

-

Overtemperature (O/T)

The condition which a furnace or oven may enter if part
of the main control circuit fails.

-

Overtemperature
Protection

A system to prevent the product or process being
damaged if it has gone into an overtemperature
condition.

-

Ramp/Dwell Pairs

A Program is split up into segments, each segment
Contains a Ramp and a dwell.

-

Program

A sequence of stored Parameters set by the operator,
which will run automatically when started.

-

Latched Alarm

Will hold the alarm condition once it has been detected.

-

Non-Latching Alarm

Will reset itself when the alarm condition is removed.

-

Power Cycling

The Power to the controller is turned off and then back
on.

-
