Quick Start Guide
7 MC18-GB – v1.04
When level 2 operations have been completed, the supervisor must return to Level 1 either
manually or by ‘power cycling’, there is no time out function.
To Return to Level 1
1. Press and hold the page Key

2. Press Down

to select
LEu 1
It is not necessary to enter a code when going from a higher level to a lower level
When level 1 is selected, the display reverts to the home display (See Section 2.1)
Table showing parameters accessible in level 1 and Level 2
Operator LEVEL 1 Supervisor LEVEL 2
Home display Home Display
Programming Programming
Program Status Program Status
Alarms (if configured)
Current Transformer Input (if configured)
Comms (if configured)
Controller setup
Customer Calibration
TIP
If while navigating the controller a parameter has been passed or you need to access
parameters which would be at the end of a scroll list, press and hold Scroll

and use Up

to return to a previous parameter.
