background image

Programming

12

MC18-GB

– v1.04

5.2

Running a Program

If using the 3216P5 controller Press Scroll

to display

PROG select the

required Program Number before running a Program.

Table below shows the key presses to run a program

Operation

Action

Indication

To RUN a program Press and quickly

release

+

Indicator

– RUN = On

Scrolling Display

Current Program state

To HOLD a
program

Press and quickly
release

+

Indicator

– RUN = Flashing

Scrolling Display

– Program Hold

To RESET a
program

Press and Hold

+

for more than

1 second

Indicator

– RUN = Off

Scrolling Display - None

Program Ended

Indicator

– RUN = Off

Scrolling Text

– Program End

To RESET a
program after it
has completed

Press and Hold

+

for more than

1 second
Or
Press and quickly
release
Ack



Indicator

– RUN = Off

Scrolling Display - None

5.3

Program Status


While the program is running in level 1 or level 2, the Home Display shows two values at
any one time:

Process Value
The upper display shows the measured temperature of the furnace (PV).

PSP, Segment Type and Number
The lower display continually alternates between the programs current set value (Program
SP = PSP) and scrolling text, indicating the current status of the program whether RAMP or
DWELLING followed by the segment number.

Additional information can be obtained using the scroll

key while the program is running.


Working Output Power
From the home display, press Scroll

until the display shows

WRK.OP <WORKING OUTPUT

POWER> This shows the power being used as a percentage.
