Introduction
4 MC18-GB – v1.04
1 Introduction to the Controller and Manual
1.1 Using This Manual
This manual aims to explain how to set up and operate the Eurotherm 3216 series of
controllers; it must be read in conjunction with the product main manual.
Due to the complex nature of furnace or oven control the use of technical terms throughout
this manual is unavo
idable. Explanations of these terms can be found in the ‘Glossary of
Terms’ at the back of this manual.
This manual covers the operation of:
1.1.1 3216P1 - Controller/Programmer
The 3216P1 is a digital temperature controller which uses PID algorithms to give excellent
temperature control. This controller can store and run a single program of 8 ramp/dwell
segments. The 3216P1 can also be used as a simple temperature controller.
1.1.2 3216P5 - Controller/Programmer
The 3216P5 is a digital temperature controller which uses PID algorithms to give excellent
temperature control. This controller can store up to 5 programs of 8 ramp/dwell segments.
The 3216P5 can also be used as a simple temperature controller.
1.2 PID Control
The 3216 series of controllers use PID (Proportional Integral Derivative) temperature
control. This type of control uses a complex mathematical control system to adjust the
power being sent to the elements and to hold the furnace or oven at the desired
temperature.
