9.0 S PECIFICATIONS
Carbolite reserves the right to change specifications without notice .
9.1 Models Covered by this Manual
MODEL Max.
Temp.
Max.
Power
Work
Tube
Bore
Work
Tube
Length
Heated
Length Uniform
Zone
Length
1
Net
Weight
2
(°C) (kW) (mm) (mm) (mm) (mm) (kg)
Tube furnaces with a ceramic work tube wound with resistance wire
TZF 12/38/400
1200°C 1.5 38 450 400 305 15
TZF 12/65/550 1200°C 2.0 65 600 550 392 25
TZF 12/75/700 1200°C 3.0 75 750 700 510 28
TZF 12/100/900 1200°C 4.5 100 950 900 745 35
also models based on the above, but of other diameters or lengths, supplied to special order
note 1: The figures for uniform zone length are for ±5°C and are based on
measurements with the furnace horizontal and fitted with insulating plugs in both tube
ends. They assume the use of master-slave control.
note 2: Weights are approximate for horizontal models and do not include fittings
or vertical stands.
9.2 Environment
The furnaces contain electrical parts and should be stored and used in indoor conditions as
follows:
temperature: 5°C - 40°C
relative humidity: maximum 80% up to 31°C decreasing linearly to 50% at 40°C
