Carbolite CF 15 - CF 60 - Manual (Page 18)

18 MF28 3.08
9.0 S PECIFICATIONS
Carbolite reserves the right to change specifications without notice .
9.1 Models Covered by this Manual
MODEL Max.
Temp.
Max.
Power
Chamber Size (mm) Net
Weight
(°C) (kW) H W D (kg)
Cupellation Furnaces, heated by Silicon Carbide elements
CF 15 1200°C 9.0 122 220 350
CF 24 1200°C 14.5 205 225 450 306
CF 50 1200°C 20 230 350 550
CF 60 1200°C 31 250 400 650
9.2 Environment
The furnaces contain electrical parts and should be stored and used in indoor conditions as
follows:
temperature: 5°C - 40°C
relative humidity: maximum 80% up to 31°C decreasing linearly to 50% at 40°C
