Apex Series Ovens
MF42 1.10
11
7.0 C IRCUIT D IAGRAMS & F USES
7.1 Circuit Without Process Timer
7.2 Circuit With Process Timer
7.3 Fuses
F1
Internal supply fuses Fitted on EMC filter board. 32mm x 6mm type F
F2
Auxiliary circuit fuses Fitted on EMC filter board. 20mm x 5mm
Customer fuses Recommended. Same as table.
Model Volts Supply Fuse Volts Supply Fuse Control Fuse
AX30 220-240 5A 110-120 10A 2A
AX60 220-240 7A 110-120 12.5A 2A
AX120 220-240 10A 110-120 20A 2A
Instrument Switch
temp.
controller
SSR
e
l
e
m
e
n
t
F1
F2
N
L
EMC Filter Unit
PE
Fan motor
Hydraulic
thermostat
Warning light
Hydraulic
t/stat if fitted
Reset
button
11
10
12
4
3 +
–
1
2
EMC Filter Unit
Instrument Switch
temp.
controller
SSR
e
l
e
m
e
n
t
F1
F2
N
L
Fan motor
process
timer
10
11
12
4
3 +
–
1
2
1
2
7
8
PE
Hydraulic
thermostat
Warning light
Hydraulic
t/stat if fitted
Reset
button
These diagrams do not apply to AX120 at 110-120V.
Please enquire if details are required.
sensor
sensor
