C.B.S. Scientific DH Series - Manual (Page 33)

C.B.S.  Scientific 33 Dedicated Height Sequencer
MICROTROUGH CASTING COMBS
20CM WIDE UNITS
33CM WIDE UNITS
Cat.# Thickness x # troughs point to point Cat.# Thickness x # troughs
MCC20-0224 0.2mm x 24 troughs 5.92mm MCC33-0246 0.2mm x 46 troughs
MCC20-0234* 0.2mm x 34 troughs 4.50mm MCC33-0262* 0.2mm x 62 troughs
MCC20-0238 0.2mm x 38 troughs 4.02mm MCC33-0268 0.2mm x 68 troughs
MCC20-0252* 0.2mm x 52 troughs 3.00mm MCC33-0294* 0.2mm x 94 troughs
MCC20-0270* 0.2mm x 70 troughs 2.25mm MCC33-02126* 0.2mm x 126 troughs
MCC20-0424 0.4mm x 24 troughs 5.92mm MCC33-0446 0.4mm x 46 troughs
MCC20-0434* 0.4mm x 34 troughs 4.50mm MCC33-0462* 0.4mm x 62 troughs
MCC20-0438 0.4mm x 38 troughs 4.02mm MCC33-0468 0.4mm x 68 troughs
MCC20-0452* 0.4mm x 52 troughs 3.00mm MCC33-0494* 0.4mm x 94 troughs
MCC20-0470* 0.4mm x 70 troughs 2.25mm MCC33-04126* 0.4mm x 126 troughs
MCC20-0524 0.5mm x 24 troughs 5.92mm MCC33-0546 0.5mm x 46 troughs
MCC20-0534* 0.5mm x 34 troughs 4.50mm MCC33-0562* 0.5mm x 62 troughs
MCC20-0538 0.5mm x 38 troughs 4.02mm MCC33-0568 0.5mm x 68 troughs
MCC20-0552* 0.5mm x 52 troughs 3.00mm MCC33-0594* 0.5mm x 94 troughs
MCC20-0570* 0.5mm x 70 troughs 2.25mm MCC33-05126* 0.5mm x 126 troughs
* Designed for multi-channel pipettor loading.
SYSTEM “96” FOR 33CM WIDE UNITS ONLY
WITH MICROTROUGH ™ SYSTEM
MICROTROUGH ™ GLASS PLATES
MICROTROUGH ™ PLUG COMBS*
Cat.# Spacer Dimensions Cat.# Spacer Dimensions
MTV96-0398 32cm (h), 98 microtroughs, 3.0mm ptp MCC96-0298 0.2mm x 98 well, 3.0mm ptp
MTV96-0498 42cm (h), 98 microtroughs, 3.0mm ptp MCC96-0398 0.3mm x 98 well, 3.0mm ptp
MTV96-0598 52cm (h), 98 microtroughs, 3.0mm ptp MCC96-0498 0.4mm x 98 well, 3.0mm ptp
MTV96-0698 62cm (h), 98 microtroughs, 3.0mm ptp *Necessary when using sharktooth combs with Microtrough
MTV96-0898 82cm (h), 98 microtroughs, 3.0mm ptp glass plates
RECTANGULAR TOOTH COMBS
SHARKTOOTH COMBS* WITH ATTACHED MICROTROUGH ™ PLUGS
Cat.# Comb Dimensions Cat.# Spacer Dimensions
MK96-0298 0.2mm x 98 well, 3.0mm ptp MRP96-0298 Rectangular/Plug Comb 0.2mm x
98 well
MK96-0398
0.3mm x 98 well, 3.0mm ptp MRP96-0398 Rectangular/Plug Comb 0.3mm x
98 well
MK96-0498
0.4mm x 98 well, 3.0mm ptp MRP96-0498 Rectangular/Plug Comb 0.4mm x
98 well
*With or without Microtrough™ System
WITHOUT MICROTROUGH ™ SYSTEM
STANDARD GLASS PLATES, NOTCHED
RECTANGULAR TOOTH COMBS
Cat.# Spacer Dimensions Cat.# Comb Dimensions
SGP96-030 32cm (h) x 33cm (w) MG96-0298 0.2mm x 98 wells
SGP96-040 42cm (h) x 33cm (w) MG96-0398 0.3mm x 98 wells
SGP96-050 52cm (h) x 33cm (w) MG96-0498 0.4mm x 98 wells
SGP96-060 62cm (h) x 33cm (w) MG96-0798 0.75mm x 98 wells
SGP96-080 82cm (h) x 33cm (w) MG96-1098 1.0mm x 98 wells
MG96-1598 1.5mm x 98 wells
MG96-2098 2.0mm x 98 wells
SPACER PAIRS BOTTOM SPACERS
FOR 20CM & 33CM WIDE UNITS FOR 20CM & 33CM WIDE UNITS
(Polycarbonate) (Polycarbonate)
Cat.# Spacer Dimensions Cat.# Spacer Thickness
SGS-2020 0.2mm x 22cm SGS-20-.2 bottom spacer 0.2mm thick
SGS-2030 0.2mm x 32cm SGS-20-.4 bottom spacer 0.4mm thick
SGS-2040 0.2mm x 42cm SGS-20-.5 bottom spacer 0.5mm thick
SGS-2050 0.2mm x 52cm
SGS-2060 0.2mm x 62cm SGS-33-.2 bottom spacer 0.2mm thick
SGS-2080 0.2mm x 82cm SGS-33-.4 bottom spacer 0.4mm thick
SGS-2100 0.2mm x 102cm SGS-33-.5 bottom spacer 0.5mm thick
SGS-4020 0.4mm x 22cm
SGS-4030 0.4mm x 32cm
SGS-4040 0.4mm x 42cm
FOR 20CM & 33CM WIDE UNITS
SGS-4050 0.4mm x 52cm Cat.# Spacer Thickness
SGS-4060 0.4mm x 62cm MKS-20-.2 bottom spacer 0.2mm thick
SGS-4080 0.4mm x 82cm MKS-20-.4 bottom spacer 0.4mm thick
SGS-4100 0.4mm x 102cm MKS-20-.5 bottom spacer 0.5mm thick
SGS-5020 0.5mm x 22cm
SGS-5030 0.5mm x 32cm MKS-33-.2 bottom spacer 0.2mm thick
SGS-5040 0.5mm x 42cm MKS-33-.4 bottom spacer 04.mm thick
SGS-5050 0.5mm x 52cm MKS-33-.5 bottom spacer 0.5mm thick
SGS-5060 0.5mm x 62cm
SGS-5080 0.5mm x 82cm
SGS-5100 0.5mm x 102cm
