25
Dedicated Height Sequencer
5.3 Comb/Well Volumes
Sequencing Combs for 20cm wide units
Note: To calculate sample well volume expressed in millimeters (mm) divide maximum volume by tooth depth.
-Volume per tooth (microliters- μl)
# of wells Tooth
width/mm
0.2mm thickness 0.4mm thickness 0.5mm thickness
8 17.7mm 33.6 μl
67
μl
84
μl
12 11mm 21 μl 41μl 52 μl
14 9mm 17.3 μl
34
μl 43μl
16 7.6mm 14.4 μl 28 μl 36μl
17* 6.6mm 12.5 μl
25
μl 31.3μl
20 5.6mm 10.6 μl 21 μl 26.5μl
28 4mm 7.8 μl 15μl 19.5μl
32 3.4mm 6.4 μl 12μl 16.5μl
35* 2.92mm 5.5 μl 11.12μl 13.9μl
*Designed for multi-channel pipettor loading
Overall length of comb: 15.87cm
Tooth depth: 9.5mm
Spacing between teeth: 8-20 wells : 2.3mm
28-35 wells: 1.5mm
Sequencing Combs for 33cm wide units
Note: To calculate sample well volume expressed in millimeters (mm) divide maximum volume by tooth depth.
-Volume per tooth (microliters-
μl)
# of wells Tooth
width/mm
0.2mm thickness 0.4mm thickness 0.5mm thickness
8 33.4mm 63.4 μl 127 μl 158.6 μl
16 15.5mm 29.5 μl 59μl 73.6μl
24 9.5mm 18 μl 36μl 45μl
31* 6.6mm 12.5 μl
25
μl 31.4μl
34 6mm 11.4 μl 22μl 28.5μl
50 4.1mm 7.7 μl 15.5μl 19.4 μl
60 3.1mm 5.8 μl 11.6μl 14.7μl
63* 2.92mm 5.5 μl 11.1μl 13.8μl
*Designed for multi-channel pipettor
Overall length of comb: 28.4cm
Tooth depth: 9.5mm
Spacing between teeth: 8-31 wells : 2.3mm
34-63 wells: 1.5mm
Ultrathin Sharktooth Combs for 20cm wide units
Note: To calculate sample well volume expressed in millimeters (mm) divide maximum volume by tooth depth.
-Volume per tooth (microliters- μl)
# of wells Tooth width/mm .075mm thickness
1 158.7mm 47.6 μl
24 5.92mm 1.6 μl
34* 4.5mm 1.2 μl
38 4.02mm 1.0 μl
52* 3.0mm .8 μl
*Designed for multi-channel pipettor Point to Point Measurements:
24 well=5.92mm
34 well=4.50mm
38 well=4.02mm
52 well=3.00mm
Ultrathin Sharktooth Combs for 33cm wide units
Note: To calculate sample well volume expressed in millimeters (mm) divide maximum volume by tooth depth.
-Volume per tooth (microliters- μl)
# of wells Tooth width/mm .075mm thickness
1 284mm 85.20
μl
46 5.92mm 1.6
μl
62* 4.5mm 1.2 μl
68 4.02mm 1.0 μl
94* 3.0mm .8 μl
*Designed for multi-channel pipettor Point to Point Measurements:
