26
Dedicated Height Sequencer
46 well=5.92mm
62 well=4.50mm
68 well=4.02mm
94 well=3.00mm
5.3 Comb/Well Maximum Loading Volumes-continued
SharktoothCombs for 20cm wide units
Note: To calculate sample well volume expressed in millimeters (mm) divide maximum volume by tooth depth.
-Volume per tooth (microliters-
μl)
# of wells Tooth
width/mm
0.2mm thickness 0.4mm thickness 0.5mm thickness
1 158.7mm 317.4 μl
634.8
μl
793.5
μl
24 5.92mm 4.5 μl 9.0μl
11.3
μl
34* 4.5mm 3.3 μl 6.6 μl 8.4μl
38 4.02mm 2.8 μl
5.6
μl 7.0μl
52* 3.0mm 2.0 μl 4.0 μl 5.0μl
70* 2.25mm 1.4 μl
2.8
μl 3.4μl
*Designed for multi-channel pipettor loading Point to Point Measurements:
24 well=5.92mm
34 well=4.5mm
38 well=4.02mm
52 well=3.00mm
70 well=2.25mm
Sharktooth Combs for 33cm wide units
Note: To calculate sample well volume expressed in millimeters (mm) divide maximum volume by tooth depth.
-Volume per tooth (microliters-
μl)
# of wells Tooth
width/mm
0.2mm thickness 0.4mm thickness 0.5mm thickness
1 284mm 539.6 μl 1079.2 μl 1349 μl
46 5.92mm 4.5 μl 9.0μl 11.3μl
62* 4.5mm 3.3 μl 6.6μl 8.4μl
68 4.02mm 2.8 μl
5.6
μl 7.0μl
94* 3.0mm 2.0 μl 4.0μl 5.0μl
126* 2.25mm 1.71 μl 3.4μl
4.2
μl
*Designed for multi-channel pipettor Point to Point Measurements:
46 well=5.92mm
62 well=4.50mm
68 well=4.02mm
94 well=3.00mm
126 well=2.25mm
