Unit parts list – Briggs & Stratton Home Generator System User Manual
Page 27
27
Briggs & Stratton Power Products Home Generator System
Owners Manual
UNIT PARTS LIST
Item Part #
Qty. Description
1
H190724GS
1
CRADLE
2
H92531GS
1
SUPPORT, Engine
3
H190723GS
1
SUPPORT, Engine & Muffler
4
92247GS
1
HOUSING, Engine Adapter
5
191308GS
1
ASSY, Rotor (Inclds Item 7)
6
94981AGS
1
ASSY, Stator
7
65791GS
1
BEARING
8
96796GS
1
WASHER, Grommet Retainer
9
22129GS
5
LOCKWASHER
10 86307GS
4
CAPSCREW, Hex Head
11 75431GS
1
CAPSCREW, Hex Head
12 92609GS
2
MOUNT,Vibration
13 82857GS
4
MOUNT,Vibration
14 67989GS
2
NUT, Flange Serrated
15 66476GS
2
CAPSCREW
16 92532GS
1
BRACKET, Muffler
17 22142GS
2
SCREW
18 B4206GS
1
MUFFLER
19 B4343GS
1
GASKET, Muffler
20 81917GS
1
PIN, Roll
21 83083GS
1
SCREEN, Spark Arrest
22 22127GS
2
NUT, Hex
23 22097GS
2
WASHER, Lock
24 22287GS
2
SCREW
25 SRV66825DGS 1
CARRIER, Rear Bearing
26 74908GS
4
TAPTITE
27 86308BGS
4
BOLT, Stator
28 65795GS
1
RECTIFIER, Battery Charge
29 66849AGS
1
TAPTITE
30 67022GS
1
GROMMET, Rubber
31 84132GS
1
ASSY, Power Regulator
32 66386GS
1
ASSY, Brush Holder
33 66849GS
2
TAPTITE
34 B4871GS
1
COVER, Bearing Carrier
35 22769GS
1
WASHER, Shakeproof Int.
36 86494GS
1
SCREW,Wing
37 188333GS
1
DECAL, Instruction, Fuel Level
38 77395GS
4
NUT, Flange Lock
39 83465GS
4
GROMMET,Tank
40 78831AGS
4
CAPSCREW, Hex Head
41 80270GS
1
VALVE,Tank
42 78299GS
1
BUSHING, Plastic Tank
43 B4363GS
1
CAP, Fuel Gauge
Item Part #
Qty. Description
44 B1998GS
1
ASSY,Tank, Fuel
(Includes Items 41 & 42)
45 J189176GS
1
SHIELD, Heat
46 92665GS
1
INSULATION
47 85000GS
1
CLIP, Insulation
48 14353621GS
1
WIRE, Ground
49 26850GS
2
LW, EXT, Shakeproof
51 92982GS
1
DECAL, Danger
52 B2153GS
7
DRILLER, Self
53 189160GS
12 NUT, Serrated Flange
54 190725GS
2
DECAL,Tank Support
57 190725GS
1
DECAL, Control Panel
58 B4690GS
1
ASSY, Control Panel
59 43116GS
4
CAPSCREW, Hex Head
60 22531GS
2
CAPSCREW, Hex Head
62 93826GS
1
DECAL, Start Instructions
63 JB4674GS
1
SHIELD, Heat
64 56893GS
5
CRIMPTITE
65 77282GS
1
SWITCH, Starter
66 B4986GS
1
DECAL, Ground
68 30340GS
1
HOSE, Fuel
69 48031CGS
2
CLAMP, Hose
70 189302CGS
2
ASSY,Wire, #13
71 13353621GS
1
ASSY,Wire, #55
72 J186704GS
1
TRAY, Battery
73 96113GS
1
ASSY,Wire, #13
74 52618GS
2
CAPSCREW, Hex Head
75 190911GS
1
MANUAL, Engine
76 52856GS
2
NUT, Hex, Flange
77 23897GS
2
WASHER, Flat
78 B4489GS
1
BATTERY
79 190732GS
1
MANUAL, Owners
80 62265GS
2
GROMMET
81 73054GS
1
DECAL, Fuel Shut-Off
82 77816GS
1
DECAL, Caution Hot Muffler
83 78549GS
1
DECAL, Electric Start
84 190780GS
1
DECAL, 1-800 BSPP
85 BB3061GS
2
BOTTLE, Oil
86 B4177GS
1
CHARGER, Battery
87 B5066GS
1
FLASHLIGHT
88 190854GS
1
MANUAL, Installation
89 24114GS
2
NUT
90 42907GS
1
CAPSCREW, Hex Head
900 NSP
1
ENGINE
