17

Briggs & Stratton Power Products Home Generator System

Owners Manual

SPECIFICATIONS

Generator

Model . . . . . . . . . . . . . . . . . . . . 01678

Rated Maximum Power . . . . . . . 6,500 Watts

Rated Maximum Load Current:

at 240 Volts . . . . . . . . . . . . . . . 27.1 Amps

at 120 Volts . . . . . . . . . . . . . . . 54.2 Amps

Rated AC Voltage . . . . . . . . . . . . 120/240 Volts

Rated Frequency . . . . . . . . . . . . 60 Hz at 3600 rpm

Phase . . . . . . . . . . . . . . . . . . . . . Single Phase

Power Factor . . . . . . . . . . . . . . . 1.0

Normal Operating Range . . . . -20°F (-28.8°C) to 104°F

(40°C)

Fuel Tank Capacity . . . . . . . . . . 8 U.S. Gallons

System Shipping Weight . . . . . . 296 lbs.

Transfer Switch

Maximum Circuits . . . . . . . . . . . 10

Maximum Load/Circuit:

from Generator . . . . . . . . . . . 27.1 Amps

from Load Center. . . . . . . . . . 50 Amps

Maximum Watts . . . . . . . . . . . . . 6,500

Power Cord Length . . . . . . . . . . 10 ft.

Connection Box Power

Inlet Connector . . . . . . . . . . . NEMA L14-30

GENERAL MAINTENANCE

RECOMMENDATIONS

The Owner/Operator is responsible for making sure that
all periodic maintenance tasks are completed on a timely
basis; that all discrepancies are corrected; and that the unit
is kept clean and properly stored. Never operate a
damaged or defective generator.

Engine Maintenance

See engine owner’s manual for instructions.

CAUTION!

Avoid prolonged or repeated skin

contact with used motor oil. Used motor oil has
been shown to cause skin cancer in certain
laboratory animals.Thoroughly wash exposed areas
with soap and water.
KEEP OUT OF REACH OF CHILDREN. DON'T
POLLUTE. CONSERVE RESOURCES. RETURN
USED OIL TO COLLECTION CENTERS.

Generator Maintenance

Generator maintenance consists of keeping the unit clean
and dry. Operate and store the unit in a clean dry
environment where it will not be exposed to excessive
dust, dirt, moisture or any corrosive vapors. Cooling air
slots in the generator must not become clogged with snow,
leaves or any other foreign material.

NOTE: Do Not use a garden hose to clean generator.
Water can enter engine fuel system and cause problems. In
addition, if water enters generator through cooling air slots,
some of the water will be retained in voids and cracks of
the rotor and stator winding insulation.Water and dirt
buildup on the generator internal windings will eventually
decrease the insulation resistance of these windings.

Battery Maintenance

Other than float charging, described elsewhere, no
maintenance is required for the battery. Keep the battery
and terminals clean and dry.

IMPORTANT: Battery charging should be performed in a
dry location, such as inside a garage.

To Clean the Generator

• Use a damp cloth to wipe exterior surfaces clean.

• A soft bristle brush may be used to loosen caked on dirt

or oil.

• A vacuum cleaner may be used to pick up loose dirt and

debris.

• Low pressure air (not to exceed 25 psi) may be used to

blow away dirt. Inspect cooling air slots and opening on
generator.These openings must be kept clean and
unobstructed.
