9
Shipping Weight 95 lbs. (115 lbs. crated)
Main Motor Baldor Model 17K017W470
Horsepower 1/3 HP
Motor Voltage 110 volt/60Hz
Amperage 5.8 Amps
Motor RPM 1725 RPM Fixed
Motor Arbor Diameter 1/2"
Duty Continuous
Motor Arbor Bearings Ball Bearings, permanently sealed
Blade Capacity 8", 9" or 10" diameter
Power Feed Motor Dayton Shaded Pole AC Gear motor (Model 3M098)
Horsepower 1/250 HP
Motor Voltage 110 volt/60Hz
Motor RPM 4 RPM (full load) Fixed
Torque 18 inch-lbs.
Rotation Clockwise facing the shaft
Motor Arbor Diameter 5/16"
Motor Arbor Bearings Sleeve-bushing type, permanently sealed
Power Feed Toggle Switch Control Positions:
1. BACK/POWER FEED Position (toward operator)– Provides power from the main motor to the blade arbor
and power feed motor.
2. MIDDLE/OFF Position – Both power feed and main motors off.
3. FORWARD/MANUAL FEED Position (away from operator) Provides power from the main motor to the blade
arbor only.
Blade Arbor Bearings: Permanently sealed 5/8" OD shaft ball bearings press fit into aluminum housing (must
be ordered with aluminum housing as an arbor assembly when bearings are worn out.)
Blade Arbor Flanges: Aluminum, 2" OD x 5/8" bore.
Power Feed Threaded Rod: 1-1/2" long x 3/8"-24 fine thread stainless steel rod.
Power Feed Clutch Block: Two piece: lower silicon bronze half-threaded 3/8"-24 fine thread and upper brass
friction block (unthreaded).
Rock Vise Capacity: 4" .
Cross Feed Index Movement per Revolution of Handle: 1/16".
Power Feed In-Feed Vice Advancement Rate: approximately 3/16 of an inch per minute.
Blade Lubricant Requirements: 1/2 gallon of oil to adequately cover the bottom of a 10” blade and 3/4 gallon for
an 8” blade.
PF10 SPECIFICATIONS
