Barranca Diamond PF10 Power Feed Trim Saw User Manual
Page 28
28
Item
Description
Qty
Part #
A
Assembly, Accessories
A1
Guard, Splash
1
161023
A2
Screw, Round Head Machine 10-32 x 1"
2
161042
A3
Spacers, Splash Guard
2
161076
A4
Washer, Flat SAE # 10
2
154369
A5
Nut, Hex 10-32
2
156269
A6
Blade, MK-303 10 x 040 x 5/8"
1
153696
C
Assembly, Tank
C1
Tank, Oil or Water
1
161016
C1A
Screw, Hex HD 5/16"-18 x 1-1/4"
4
153950
C2
Plug, Drain 1/2"
1
161021
D
Assembly, Holding Vise
D1
Vise, Front Jaw
1
161027
D2
Vise, Rear Jaw
1
161028
D3
Wood Liner, Front Jaw
1
161031
D4
Wood Liner, Rear Jaw
1
161032
D5
Screw, Flat HD 10-32 x 1/2"
4
154541
D6
Nut, Hex 3/8"-16
1
101188
D7
Nut, Wing 3/8"-16
3
161037
D8
Washer, Flat SAE 3/8"
2
150923
D9
Handle, Cross Feed
1
161044
D10
Collar, Side Feed
1
161077
D11
Screw, Set 10-32 x 3/16"
2
161038
D12
Rod, Threaded 3/8"-16 x 6"
2
161034
D13
Rod, Threaded 3/8"-16 x 7"
1
161081
E
Assembly, Engage
E1
Bracket, Clutch
1
161060
E2
Handle, Clutch Engage
1
161061
E3
Clutch
1
161062
E4
Collar, Clutch Engage
1
161063
E4A
Screw, Set 8-32 x 1/4"
1
161086
E5
Screw, Rnd Head Machine 10-32 x 1-1/2"
3
161064
E6
Washer, Flat SAE # 10
5
154369
E7
Nut, Hex 10-32
4
156269
F
Assembly, Belt Guard
F1
Guard, Belt 16 GA. (steel)
1
161072
PF10
PARTS LIST
