Network Receiver
18 750.001.005 R04 © 2005 AXCESS Inc.
Setting the Receiver ID
Receiver IDs are used by ActiveTrac software to determine from
which zone a Tag reported. By default, the Receiver ID is 001. To give
the Receiver a new ID, type:
I (< number > = a number between 000 and 999.)
Enabling TTL Outputs (Logic Control)
The Network Receiver has two TTL outputs (Transistor-Transistor-
Logic). Each can be set to go from Low (inactive) to High (active) upon
a Tag read. The output level is 3.3 V DC. The following table provides
a list of configuration commands:
TTL Output 1 TTL Output 2 Action
D E Set length of action signal in seconds.
Valid numbers are 000 – 255. Default:
005 seconds
10c 11c Pulse the output to go from Low to
High
16c 17c Deactivates TTL output for a valid Tag
read. Default.
30c 31c Activate TTL output for a valid Tag read.
13c 14c Do not activate TTL output when the
alarm code is received from a Panic or
Tamper Tag. Default.
27c 28c Activate TTL output when an alarm
code received is from Panic or Tamper
Tag
