Figure 7c
Pole Pin
Center Pole
Figure 7b
Center Pole
Cables
Lock Pin
Roller
Step 8 Lift Other Side
Raise opposite side by repeating Step 5. Attach remaining uprights.
Plumb uprights.
Step 9 Installing Optional Walls
Determine proper mating of 2-piece walls with labels
on the inside. Slide tabs at top of walls into bottom
outside channel opening (see Century Frame extru-
sion drawing on Page 3).
Orient walls so that beading edges are adjacent to
uprights and the lace edges meet in the middle.
Step 10 Attach Walls to Uprights
At each upright gather up wall and insert bottom of beading into
channel opening at top of upright. Feed all of beading into chan-
nel.
Figure 9
Figure 10
6
