3.12 Others
3.12.1 In Others you can setup Auto Config, PTT Setting and ICMP Setting function. The function
can configure your VoIP Phone automatically.
3.12.2 Auto Config: you can setup the Auto Configuration Enable/Disable and auto configuration
by FTP or TFTP. You need to select the way to do the Auto Configurationand set the Server
IP address in this page. This function can automatically download the configure file to
setup your TA.
3.12.3
When you have finished the setting, please click the Submit button.
3.12.4 If no further changes are needed, please click the Save Change Item on the left side; then
click the Save button. The changes you have made will be saved and the system will reboot
automatically.
Figure 28. Auto Configuration Setting
Auto Configuration Default setting is Off (not executed). Specify the methods on how auto
configuration will be performed, the options are TFTP, FTP or HTTP.
TFTP Server Set the TFTP Server’s location, you can input IP address or Domain Name
information in this text box.
HTTP Server Set the HTTP Server’s location, you can input IP address or Domain Name
information in this text box.
HTTP Path Specify the path to store data, for e.g. /123/
FTP Server Set the FTP Server’s location, you can input IP address or Domain Name
information in this text box.
FTP Username Enter the relevant Username to log on to the FTP Server。
FTP Password Enter the relevant password associated with the inputted username to log
on to the FTP Server
File Path Specify the path to store data, for e.g. /123/
Submit [Button] Saves the configuration
Reset [Button] Erases the configuration
