AirLive DS-100 User’s Manual
30
This section provides the specifications of DS-100, and the following table lists these
specifications.
Standard
IEEE802.3 10BASE-T
IEEE802.3u 100BASE-TX
Interface
1 x 10/100/ RJ-45 port
2 x RS-232 DB-9 port
Data Bits
5, 6, 7, 8
Stop Bits
1, 1.5, 2
Parity
None, Even, Odd, Space, Mark
Flow Control
RTS/CTS and DTR/DSR (RS-232 only), XON/XOFF
Baud rate
50 bps to 921.6 Kbps
Network Protocols
ICMP, IP, TCP, UDP, DHCP, BOOTP, Telnet, SNMP, HTTP
Management Interface
Web management via web browser
Temperature
Operating: 0 to 40°C
Storage: -10 to 70°C
Humidity
Operating: 10% ~ 90%
Storage: 5% ~ 90%
Power Adapter
Input: 100~240VAC 50/60Hz (maximum)
Output: 12V / 1A
Produce Weight (g)
280 g
Dimensions
Without ears: 90.00 x 109.39 x 31.27 mm
With ears: 116.00 x 109.39 x 31.27 mm
Standard
IEEE802.3 10BASE-T
IEEE802.3u 100BASE-TX
Interface
1 x 10/100/ RJ-45 port
2 x RS-232 DB-9 port
Data Bits
5, 6, 7, 8
Stop Bits
1, 1.5, 2
Parity
None, Even, Odd, Space, Mark
Flow Control
RTS/CTS and DTR/DSR (RS-232 only), XON/XOFF
Baud rate
50 bps to 921.6 Kbps
Network Protocols
ICMP, IP, TCP, UDP, DHCP, BOOTP, Telnet, SNMP, HTTP
Management Interface
Web management via web browser
Temperature
Operating: 0 to 40°C
Storage: -10 to 70°C
6
6.
Specifications
