9 Technical details
/Servic e and Support/ Ser vic e & Support @ 2\ mod_1254312498746_6. doc @ 6472 @
*The details of the typical current consumption does not include any device connected to the Universal Serial Bus ports (USB)
peripheral.
Device data
VMT7008 VMT7010 VMT7012 VMT7015
Housing
Diecast aluminium, powder-coated
Front panel
Glass-fibre reinforced plastic, painted
Display
Resolution
Represented colours
8" TFT
800 x 480 pixels
max. 16.2 million 10.4" TFT
1024 x 768 pixels
max. 16.2 million 12.1" TFT
800 x 600 pixels
1024 x 768 pixels
max. 256k colours 15.1" TFT
1024 x 768 pixels
max. 16.2 million
Touch
Automatic or manual display brightness adjustment / optional: Sunlight-readable
Processor
Intel® Atom™ N2600 1.6 GHz (Dual Core)
RAM
4 GB DDR3
Graphics
controller
Intel® SCH US15W with integrated graphics
Graphic memory 7
A minimum of 8 MB shared memory
Mass storage
mSATA 8, 16, 32, 64 GB
- Alternatively: 2.5 " automotive hard disk with a minimum of 80 GB
(SATA)
2.5" SSD 8, 16, 32, 64 GB
Interfaces
COM 1 (RS232 5V, supply can be activated for scanner)
1 x USB 2.0 5 in front panel
3 x USB 2.0 5
(All external USB interfaces in high current design up to 1A)
Optional: COM2 (RS232, RS485 or CAN)
Network
2 x Ethernet (10/ 100/1000MBit) RJ 45
Sound
Sound output via two internal speakers
Radio As an option: Internal WLAN Modul 802.11 (a/b/g/n) with 3 WLAN antennas for 3 x 3n
As an option: Connector for an external antenna (R-SMA plug-in via servicing access)
Power adapter
24 V DC (10 to 36 V DC)
48 V DC (18 to 60 V DC)
Typ. Switch on
current*
typ. 0,70 A typ. 0,95 A typ. 1,10 A typ. 1,30 A
Operating system
Windows® Embedded Standard 7 MUI
Windows® 7 Ultimate FES MUI
Windows® Embedded 8 Standard
Windows® Embedded 8 Professional
Protection class
IP65
Operating temperature –20 to +55 °C (depending on mass storage device)
- Optional: -30 to +55°C (depending on mass storage medium)
Dimensions (W x H x D)
254 x 182 x 62 mm 294 x 240 x 62 mm 338 x 261 x 62 mm 400 x 305 x 65 mm
Weight
approx. 2.1 kg approx. 2.9 kg approx. 3.3 kg approx. 4.3 kg
Vibration and shock resistance
EN 60721-3-5 (06.1998), class 5M2 for HDD version, class 5M3 (terrestrial vehicles) for SSD
version, 5 hours of noise-type vibrations; 3.6 g rms and 30 g peak value
MIL - STD 810F (01.2000) Annex C. Fig. 514.5C (US Highway Truck Transportation)
Humidity
10 to 85% non-condensing
