5.4 Status displays

SYS LED (bicoloured)

Depending on the colour and type of flashing different device states are displayed by the SYS LED.

Fig. 11:

The following signals are displayed:

System LED indicators

Behaviour

Description

green/

static

Device is connected to a power
source and switched on

orange/
flashing

Volume / display brightness is
being modified

orange/
flashing

Minimum / maximum value for
volume / display brightness is
reached
