2N VoiceBlue MAX v1.4 - Manual (Page 52)

52
2N TELEKOMUNIKACE a.s., www.2n.cz
®
Others
Text of SMS at no answer – type the text of the SMS to be sent to the called
subscriber in the event of no answer (+ the function is active). The %N string
inserts the CLIP received from VoIP into the SMS.
Text of SMS for all calls – fill in this parameter to make the GSM gateway send
an SMS message to every called subscriber regardless of whether or not the call
was connected. The %N string inserts the CLIP received from VoIP into the SMS.
Save received SMS to – select the storage for SMS received.
SIM card identification – select the SIM IMSI/SCID for CDRs.
Disable CLIP from GSM/UMTS to VoIP/FXS – enable/disable resending the CLIP
from GSM to VoIP/FXS.
Reject call with CHLD – reject incoming GSM/UMTS calls by means of AT+CHLD
(user busy) instead of standard ATH.
Activate SIM Toolkit – enable the SIM Toolkit service.
Network registration timeout [min] – set the timeout after which the module
must log in. The login process will be restarted after this timeout.
GSM Group Assignment
You can assign the GSM/UMTS modules to groups separately for incoming and outgoing
calls. See the two items below for outgoing and incoming group settings.
GSM Outgoing Groups
2N VoiceBlue MAX
®
allows you to work with two groups of outgoing calls for each of
which you can set variable connection set-up modes and count of used minutes and
sent SMS messages for a selected period.
General settings
Delay for CONNECT [s] – define a delay before sending information on the
connected call after receipt from GSM.
Minimum ring duration to send SMS at no answer [s] – set the minimum ringing
time for an outgoing call to GSM/UMTS before the SMS at no answer is sent.
Delay for ALERTING [a] – define a delay before sending information on ringing
start.
off – no Alerting message will be forwarded.
real – the Alerting message will be forwarded as soon as the gateway
receives Alerting from the wireless network or ring tone detectors detect
the alerting tone (if active).
1-20 – the Alerting message will be automatically sent after a predefined
number of seconds after the call is dialled into wireless network.
Minute parameter – select whether or not the GSM gateway should record the
call length or count for outgoing call restriction.
Note
The function works properly only if the INVITE SMS at no answer
message contains the called and caller numbers.
