2N VoiceBlue Next v3.7 - Manual (Page 52)

52
2N TELEKOMUNIKACE a.s., www.2n.cz
®
Others
Text of SMS at no answer – edit the text of the SMS to be sent to the calling
party in case of no answer (if the function is active). The %N string will insert the
CLIP received from VoIP in the SMS text.
Text of SMS for all calls – fill in this parameter to make the GSM gateway send
an SMS message to every called subscriber regardless of whether or not the call
was connected. The %N string inserts the CLIP received from VoIP into the SMS.
Save received SMS to – select the storage for SMS received.
SIM card identification – select the SIM IMSI/SCID for CDRs.
Disable CLIP from GSM/UMTS to VoIP – enable/disable resending the CLIP from
GSM to VoIP.
Reject call with CHLD – reject incoming GSM/UMTS calls by means of AT+CHLD
(user busy) instead of standard ATH.
Activate SIM Toolkit – enable the SIM Toolkit service.
Network registration timeout [min] – set the timeout after which the module
must log in. The login process will be restarted after this timeout.
GSM group assignment
You can assign the GSM/UMTS modules to groups separately for incoming and outgoing
calls. See the two items below for outgoing and incoming group settings.
GSM outgoing groups
2N VoiceBlue Next
®
allows you to work with two groups of outgoing calls for each of
which you can set variable connection set-up modes and count of used minutes and
sent SMS messages for a selected period.
General settings
Delay for CONNECT [s] – define a delay before sending information on the
connected call after receipt from GSM.
Minimum ring duration to send SMS at no answer [s] – set the minimum ringing
time for an outgoing call to GSM/UMTS before the SMS at no answer is sent.
Delay for ALERTING [a] – define a delay before sending information on ringing
start.
off – no Alerting message will be forwarded.
real – the Alerting message will be forwarded as soon as the gateway
receives Alerting from the wireless network or ring tone detectors detect
the alerting tone (if active).
1-20 – the Alerting message will be automatically sent after a predefined
number of seconds after the call is dialled into wireless network.
Minute parameter – select whether or not the GSM gateway should record the
call length or count for outgoing call restriction.
Day of deleting statistics in group (every month) – define a day on which
statistics on disconnected calls should be deleted.
Note
The function works properly only if the INVITE SMS at no answer
message contains the called and caller numbers.
