2.3 Installation Conditions
Make sure that the following
installation conditions are met:
2N Indoor Touch
®
There must be enough space for
installation.
2N Indoor Touch
®
is designed for vertical wall mounting (perpendicular to the
2N
Indoor Touch
®
floor) in the height of up to 120 cm above the floor. If necessary, operate 2N
®
in a position other than as aforementioned for a short time only,
Indoor Touch
for quick testing purposes in a servicing centre, for example.
Exceeding the allowed operating temperature may not affect the device
immediately but leads to premature ageing and lower reliability. Refer to
for the acceptable range of operating temperatures and
relative humidity values.
2N Indoor Touch
®
is not designed for environments with increased vibrations
such as means of transport, machine rooms and so on.
2N Indoor Touch
®
is not intended for dusty environments and places with
.
unstable humidity and abrupt temperature changes
2N Indoor Touch
®
may not be exposed to aggressive gas, acid vapours,
solvents, etc.
2N Indoor Touch
®
is not intended for direct connection into the
Ethernet/Internet.
2N
Indoor Touch
®
must be connected to the Ethernet/Internet via a separating
(switch/router).
active network element
2N Indoor Touch
®
is designed for indoor use. It may not be exposed to rain,
flowing water, condensing moisture, fog, etc.
2N
Indoor Touch
®
cannot be operated on places exposed to direct sunshine
and near heat sources.
Keep some free space above and below
to allow air to flow
2N
Indoor Touch
®
and conduct heat away.
No strong electromagnetic radiance is allowed on the installation site.
The VoIP connection must be configured properly according to the SIP and other
VoIP recommendations.
It is recommended that the power adapter be connected to the mains via a UPS
and reliable overvoltage protection.
Wall Mounting
2N Indoor Touch
®
is designed for wall mounting. Follow the steps below:
Unscrew the holder-fitting screws on the device sides.
Turn the metal holder slightly aside in
.
the upper part of the device
Move the holder downwards.
Fit the loose holder to the wall on the installation site.
Put the device on the holder and tighten the safety screws.
Follow the installation instructions printed on the device package.
Power Supply Connection
You can feed
as follows:
2N Indoor Touch
®
