PN 18280-00 R041306

10

AssEMbLY

2.1 TIREs AND RIMs (DoMEsTIc AND s MoDELs oNLY)

2.2 TRAILER hITch (DoMEsTIc AND s MoDELs oNLY)

2

Before inspecting or servicing any part of this machine, shut

off power source, disengage the hydraulics, remove igni-

tion key and make sure all moving parts have come to a

complete stop.

WARNINg

If any bolts or nuts are dropped in the machine, be sure to

remove them before starting the machine. Remove items

from the shredder area by removing the discharge screen.

IMpoRTANT

Mount tires and rims to the axle using the lug nuts.
Attach the fender supports to the trailer using three 1/2" x 3-1/2" hex bolts, washers & nuts.
Attach the fenders to the fender supports using four 3/8" x 1" carriage bolts, washers and nuts.

1.
2.
3.

S & F-MODELS:

Thread the wire harness through the hitch tube and slide

the hitch tube into the trailer frame. Secure using two 1/2" x

4-1/2" bolts, washers and nuts (provided in owner's kit).
Slide the hitch coupler onto the hitch tube from the top and

secure using 1/2" bolts, nuts and washers.
Thread the wire harness through the metal loop on the un-

derside of the coupler.

1.

2.

3.

2.3 REAR sTAbILIzER

verify that the rear stabilizer is installed. To install the rear stabilizer, slide the stabilizer into the corresponding bracket beneath the

rear of the chipper frame. Adjust the stabilizer and secure with the provided snap pin.

DOMESTIC MODELS:
Thread the wire harness through the hitch tube and slide the

hitch into the trailer frame. Secure using two 1/2" x 4-1/2" bolts,

washers and nuts (provided in owner's kit).

Check the oil level and, if needed, fill the engine crankcase with the type and amount of oil specified in the engine owner's manual.

2.4 chEckINg/ADDINg MoToR oIL To ENgINE
