PTO CHIPPERS 15
5.1 insTalling THe sensor
Section
elecTronic Feed sensor
oPTional kiT For HYdraulic Feeds
sTandard on 76854
remove the drive belt guard. 1.
On the collar located on the rotor shaft behind the 2.
chipper drive pulley, replace the set screw with the
5/16" x 1-1/2" bolt.
using the existing bearing bolt, attach the sensor and
3.
bracket under one of the lower rotor bearing bolts so
that it lines up with the 5/16" x 1-1/2" bolt from Step
2.
remove outer and inner plugs from the relief valve and
4.
install the solenoid cartridge valve and coil..
connect the solenoid valve and harness to the lOfa
5.
control and attach the ground wires to the frame. route
positive lead near the hitch. Tie wires to the chipper
frame using the nylon straps provided.
replace the drive belt guard.
6.
attach the chipper to the tractor. connect the positive 7.
lead to a +12 volt dc power source.
Mount lOfa control and route wires according to
8.
figure 5.1.3.
Program the system using the instructions included
9.
with the feed kit and operate the chipper per manual
instructions.
noTe
refer to the pictures and illustration on the next page
when following these steps.
5.2 loFa conTrol Programming
sTeP 1. iniTiaTing Program mode
hold down the “S” button while turning the engine key to
the “on” position until “l” starts to flash on the lcd.
sTeP 2. enTer loW (l = loW) rPm
The low setting is the rPM speed where the feed roller
stops. The “up” arrow increases the rPM setting, while
the “down” arrow decreases the rPM setting. Setting the
speed lower causes the engine to lug down more before
the feed roller stops.
hold the appropriate (either up or down) arrow until 1.
the desired rPM speed is displayed (recommended
1375 rpm).
Push the “S” button once with the desired rPM setting 2.
displayed to save. do not choose a setting equal to
or below zero.
sTeP 3. enTer normal
(n = normal) rPm
The normal setting is the rPM speed that the chipper rotor
usually rotates
hold the appropriate (either up or down) arrow until 1.
the desired rPM speed is displayed (recommended
1500 rpm).
Push the “S” button once with the desired rPM setting
2.
displayed to save.
sTeP 4. enTer HigH (H = HigH) rPm
The high setting is not needed with this application.
Set to zero to deactivate. 1.
Push the “S” button once with zero displayed to 2.
save.
sTeP 5. enTer reTurn
(reT = reTurn) rPm
The return setting is the rPM speed where the feed roller
restarts. The feed roller should restart before the rotor
reaches “normal” rPM to maximize chipper efficiency.
Setting the speed higher allows the engine to recover more
before the feed roller restarts.
hold the appropriate (either up or down) arrow until 1.
the desired rPM speed is displayed (recommended
1400 rpm).
sTeP 6. enTer number oF Poles (iPu=number
oF Poles)
The number of poles is used to indicate the number of
speed pickup devices.
hold the appropriate (either up or down) arrow until 1.
(1) is displayed.
Push the "S" button once with one (1) displayed to
2.
save.
