Page 27

If the Source / Status LED continues to blink green (slower than “no signal” mode); or
OSD display shows

, please check the TVs that are connected to the transmitter and

receiver support 3D video format and try to switch the 3D video format to one of the 3D
timings listed below.

Mandatory CEA 3D Video Format Timings

Support

1280x720p @ 50Hz Top-and-Bottom

Yes

1280x720p @ 50Hz Frame packing

Yes

1280x720p @ 59.94 / 60Hz Top-and-Bottom

Yes

1280x720p @ 59.94 / 60Hz Frame packing

Yes

1920x1080i @ 50Hz Side-by-Side (Half)

Yes

1920x1080i @ 59.94 / 60Hz Side-by-Side (Half)

Yes

1920x1080p @ 23.98 / 24Hz Top-and-Bottom

Yes

1920x1080p @ 23.98 / 24Hz Frame packing

Yes

Audio Bit Rate Support

• Digital Audio from HDMI inputs: Up to 6Mbit/s bit-rate support.
• Support AC3 and DTS.
• 2-channel PCM: 16~24 bits audio sample with 32~96KHz sampling rate as below:

2channel PCM

32KHz

44.1KHz

48KHz

96KHz

16 bits

YES

24 bits

YES
