SECTION 2 GROUND COMPONENTS
71
4280280
Strip, Air Intake
1
72
3600206
Gear Pump Assembly (See Figure 2-12 for
Breakdown)
1
73
3790152
O-Ring
1
74
0641812
Bolt 1/2"-13NC x 1 1/2"
2
75
4761800
Lockwasher 1/2"
2
76
3536144
Cover, Battery (Prior to S/N44593)
1
1670841
Cover, Battery (S/N44593 to Present)
1
77
0641405
Bolt 1/4"-20NC x 5/8"
4
78
4761400
Lockwasher 1/4"
4
79
Hardware Options:
A/R
4751400
Flatwasher 1/4" (Prior to S/N 60098)
4
1320060
Clamp (S/N 60098 to Present)
2
80
3740067
Relay
1
81
4751400
Flatwasher 1/4" (Prior to S/N 60098)
8
82
3311405
Locknut 1/4"-20NC
4
83
4711400
Flatwasher 1/4" Narrow (S/N 26766 to Present Only)
1
84
0700605
Bolt, Metric 6mm x 10mm
(S/N 26766 to Present Only)
2
85
Fuse Options:
A/R
Not Required
EN280 And Australian Spec
0
2400054
CE Spec (35 Amp)
1
86
Holder, Fuse Options:
A/R
Not Required
EN280 And Australian Spec
0
2400044
CE Spec
1
87
0741008
Screw, Flathead #10-24NC x 1"
A/R
88
4751000
Flatwasher #10
A/R
89
3311005
Locknut #10-24NC
A/R
90
Bracket, Fuse Mounting Options:
A/R
Not Required
EN280 And Australian Spec
0
0902376
CE Spec
2
91
Switch, Battery Disconnect Options:
A/R
Not Required
EN280 And Australian Spec
0
4360155
CE Spec
1
92
Bracket, Switch Mounting Options:
A/R
Not Required
EN280 And Australian Spec
0
0902377
CE Spec (Prior to S/N 71229)
1
93
Cable, Battery Options:
A/R
Not Required
EN280 And Australian Spec
0
1060044
CE Spec
1
94
Decal - Battery Connect and Disconnect Options:
A/R
Not Required
EN280 And Australian Spec
0
1703476
CE Spec
1
95
0100011
Loctite #242 (Not Shown)
A/R
96
0701016
Bolt Metric 10mm x 40mm (S/N 55667 to Present)
2
97
4832000
Lockwasher (S/N 55667 to Present)
2
98
4740308
Spacer (S/N 55667 to Present)
2
99
0840046
Boot, Battery (Not Shown - Positive)
1
100
0840047
Boot, Battery (Not Shown - Negative)
1
101
2220273
Fitting, Reducer (Not Shown)
2
FIGURE 2-9. ENGINE INSTALLATION - DEUTZ F2L1011 (CONTINUED)
