JLG 40RTS Parts Manual User Manual
Page 205
3120827
8-3
S
E
C
T
I
O
N
8
D
E
C
A
L
S
SECTION 8 ELECTRICAL
FIGURE 8-1. DECALS INSTALLATIONS.
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
DECALS INSTALLATION
Ref.
0253661
Decal Installation - Common Parts
Ref.
9
0271148
Decal Installation - JLG
Ref.
1
1
Decal - JLG Options:
2
1701832
(Prior to S/N 81608)
1701871
(S/N 81608 to Present)
2
4420039
Tape, Safety Tread (Prior to S/N 65031)
3ft/.9m
3
1701871
Decal - JLG (Prior to S/N 81608)
3
4
0860520
Box, Manual Storage
1
5
1060279
Cable, Lanyard
1
6
Decal - Manual Options:
1
Use 1701509
Prior to S/N 102555 (was p/n 1703788)
1701509
S/N 102555 to Present
7
0641405
Bolt 1/4"-20NC x 5/8"
4
8
4751400
Flatwasher 1/4"
4
9
4761400
Lockwasher 1/4" (Prior to S/N 71528)
4
10
3311405
Locknut 1/4"-20NC
4
11
1701843
Decal - Sizzor (Prior to S/N 81608)
2
12
1701837
Decal - Stripe (Black) (Prior to S/N 67941)
30ft/9m
13
Not Available
Decal - Bar Code
1
14
Decal - Tie Down Options:
4
Use 1703814
S/N45396 to S/N 71528 (was p/n 1702300)
1703814
S/N 71528 to Present
15
1703811
Decal - Lifting Lug (S/N 71528 to Present)
4
16
4420067
Tape, Safety Tread (S/N 71528 to Present)
2ft/.6m
---------------------------------------------------------------
2902075
Kit, Decal (Includes Items 6,14 & 15)
1
DECAL INSTALLATIONS - MODEL SPECIFIC
Ref.
0257583
Australian 25RTS
Ref.
4
0257584
Australian 33RTS
Ref.
4
0257585
Australian 40RTS
Ref.
4
0253667
Dutch 25RTS
Ref.
4
0253674
Dutch 33RTS
Ref.
4
0253681
Dutch 40RTS
Ref.
4
0253663
Euro English 25RTS
Ref.
5
0253670
Euro English 33RTS
Ref.
4
0253677
Euro English 40RTS
Ref.
4
0253664
French 25RTS
Ref.
4
0253671
French 33RTS
Ref.
4
0253745
French 40RTS
Ref.
4
0253665
German 25RTS
Ref.
4
0253672
German 33RTS
Ref.
4
0253679
German 40RTS
Ref.
4
0253666
Italian 25RTS
Ref.
4
0253673
Italian 33RTS
Ref.
4
0253680
Italian 40RTS
Ref.
4
0253668
Spanish 25RTS
Ref.
4
