3120827 2-57
S
E
C
T
I
O
N
2
G
R
O
U
N
D
C
O
M
P
O
N
E
N
T
S
SECTION 2 GROUND COMPONENTS
FIGURE 2-13. GROUND CONTROL BOX INSTALLATION
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
GROUND CONTROL BOX INSTALLATION OPTIONS: Ref.
GROUND CONTROL BOX ASSEMBLIES Ref.
0253726 All Deutz Engine Machines (Prior To April 1993) Ref. —
0254104 All Deutz Engines Machines (April 1993 To
S/N 50053) Ref. 6
0254104 CE Spec Deutz Engines Machines (S/N 50053 To
Present) Ref. 11
0258641 Australian Spec Deutz Engines Machines
(S/N 50053 To Present) Ref. 5
0253725 Ford Engine Machines (Prior To April 1993) Ref. —
0254103 Ford Engine Machines (April 1993 To Present) Ref. 7
1 Box, Ground Control Options: 1
4843375 Prior To April 1993
4844562 April 1993 To S/N 70902
0861338 S/N 70902 To Present
2 Lid Options: 1
3252252 Prior To April 1993
3252308 April 1993 To S/N 65031
3252635 S/N 65031 To Present
3 4420037 Strip, Rubber 3ft/.9m
4 3740049 Relay A/R
5 4761400 Lockwasher 1/4" A/R
6 3311401 Nut 1/4"-20NC A/R
7 Rail, Mounting Options: 1
3640621 Prior To April 1993
3640865 April 1993 To Present
8 4460298 Block, Terminal A/R
9 4460301 Marker, Terminal 1
10 4460299 Stop, Terminal 2
11 4460300 Barrier, Terminal 1
12 4460309 Bar, Buss - 3 Position 1
13 4460305 Screw A/R
14 4460306 Washer A/R
15 4460307 Sleeve A/R
16 4360216 Breaker, Circuit - 30 Amp 1
17 4770600 Starwasher #6 2
18 3310601 Nut #6-32NC 2
19 4360232 Breaker, Circuit - 15 Amp 1
20 4761000 Lockwasher #10 A/R
21 3311001 Nut #10-24NC A/R
22 4460051 Connector, Strain Relief A/R
23 4460071 Connector, Strain Relief (Prior to S/N 74818 Only) 1
24 3300048 Locknut, Conduit 4
25 0960238 Bushing 4
26 2420009 Hourmeter 1
27 2420091 Voltmeter 1
28 3520028 Plug, Hole 1
